DPA 4041-SP
Product description
Specifications 4041-SP LARGE DIAPHRAGM MICROPHONE, P48 Directional pattern: Omnidirectional Principle of operation: Pressure Cartridge type: Condenser w. stainless steel diaphragm Frequency range: 20 Hz - 20 kHz Frequency range, ±2 dB: 20 Hz - 20 kHz with 4 - 6 dB soft boost at 8 kHz Sensitivity, nominal, ±2 dB at 250 Hz: 70 mV/Pa; -23 dB re. 1 ...
Specifications
4041-SP LARGE DIAPHRAGM MICROPHONE, P48
- Directional pattern: Omnidirectional
- Principle of operation: Pressure
- Cartridge type: Condenser w. stainless steel diaphragm
- Frequency range: 20 Hz - 20 kHz
- Frequency range, ±2 dB: 20 Hz - 20 kHz with 4 - 6 dB soft boost at 8 kHz
- Sensitivity, nominal, ±2 dB at 250 Hz: 70 mV/Pa; -23 dB re. 1 V/Pa
- Equivalent noise level, A-weighted: Max. 8 dB(A) re. 20 µPa
- Equivalent noise level, ITU-R BS.468-4: Max. 20 dB
- S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL): 86 dB(A)
- Total harmonic distortion (THD):< 0.5% THD up to 120 dB SPL peak, < 1% THD up to 126 dB SPL peak
- Dynamic range: Typ. 118 dB
- Max. SPL, peak before clipping: 134 dB
Show more
Show less
Product specifications
- Article number
- DPACon40416791
